DMG GILDEMEISTER CTX 510 TURNING MACHINE
DMG GILDEMEISTER CTX 510 TURNING MACHINE - Image 2
DMG GILDEMEISTER CTX 510 TURNING MACHINE - Image 3
DMG GILDEMEISTER CTX 510 TURNING MACHINE - Image 4
DMG GILDEMEISTER CTX 510 TURNING MACHINE - Image 5
DMG GILDEMEISTER CTX 510 TURNING MACHINE - Image 6
DMG GILDEMEISTER CTX 510 TURNING MACHINE - Image 7

DMG GILDEMEISTER CTX 510 TURNING MACHINE

  • DMG Fanuc 32
  • Maximum turning diameter:465mm
  • Maximum passage diameter:680mm
  • Maximum passage daimeter over the transverse slide:465mm
  • Feed in the x/z axis :300/1050mm
  • Accelerated feed in the x/z axis:30m/min
  • Maximum spindle speed :3500rpm
  • Spindle bore:76mm
  • Spindle drive power (40%100%DC):42/31kw
  • Maximum rotational speed of driven tools:4000rpm
  • Power installed:50kva
  • Power supply:400v;50/60Hz
  • Machine weight:7500k
Category:
Add to quote
  • DMG Fanuc 32
  • Maximum turning diameter:465mm
  • Maximum passage diameter:680mm
  • Maximum passage daimeter over the transverse slide:465mm
  • Feed in the x/z axis :300/1050mm
  • Accelerated feed in the x/z axis:30m/min
  • Maximum spindle speed :3500rpm
  • Spindle bore:76mm
  • Spindle drive power (40%100%DC):42/31kw
  • Maximum rotational speed of driven tools:4000rpm
  • Power installed:50kva
  • Power supply:400v;50/60Hz
  • Machine weight:7500k
